Ideal SURETEST® Circuit Analyzer

IDEAL’s SureTest is a comprehensive branch circuit analyzer that allows you to “look behind walls” to find wiring problems saving you time and money while letting you get the job done with safety and confidence.

Download

Download


For more info please visit: SureTest® Circuit Analyzer | IDEAL Electrical (circuit-analyzer.com)

SAFETY

ELECTRIC SHOCK HAZARDS

SureTest helps you to verify proper installation and periodically test branch circuits to confirm integrity of wiring and protection devices to ensure continued protection from shock hazards.

ELECTRICAL FIRES

Many residential fires are the result of a high resistance point leading to arcing within a branch circuit. Loose and corroded connections, bad splices, faulty cords and defective devices are common causes of many structural fires. (NFPA and US Consumer Product Safety Commission 1997 data). Branch circuit testing using the SureTest analyzer can help identify most potentially dangerous wiring conditions.

CAT III 300V OVERVOLTAGE PROTECTION

The device is intended for use ONLY on 120 VAC H-N circuits but has a generous safety margin for reliable operation.

PRODUCTIVITY

  • True RMS provides accurate readings

  • Conducts testing without disturbing sensitive loads or tripping breakers

  • Identifies proper wiring polarity in 3 wire receptacles

  • Identifies false (bootleg) grounds, without opening up the outlet

  • Indicates voltage drop and impedance on live hot, neutral and ground conductors

  • Allows you to zero in on the problem conductor and gives you clues as to the nature of the issue

VALUE

  • Includes carrying case and 1-ft. extension cord

  • SureTest measures 6 different parameters:

    • Voltage drop under load

    • line voltage

    • ground to neutral voltage

    • ground impedance

    • frequency

    • GFCI

  • Provides:

    • GFCI trip time in Milliseconds and trip current.

    • Estimated load on line in amps.

    • Hot neutral and ground impedance ON A LIVE CIRCUIT

  • 2 year warranty

Demo Videos

Circuit Analyzer Video

Polarity Video

Voltage Drop Video

GFCI Video

EEL Video

Line Voltage Video

Impedance Video
